The Mini Mate series typifies the options of Lieberts building block system of components. Trying to make a complete listing of units would be a messy bunch of numbers. So we have copied the model number charts for the various sizes to make it as simple as possible. SEE BOTTOM OF PAGE. Please call to figure out what you actually need.

The Challenger Series has carry over components from the Mini Mate / Datamate ceiling mounted units. Again Liebert / Vertiv making things as components that fit multiple units with different applications. Therefore this section can be very confusing. So please call to fit units to your actual need.

Tons  -  Heat Rejection         -          Old Models         -       DS Models        -        PX & PW Models

3  -  Air Cooled (Condensing Sec.) -  BF036E, BU036E      =          Same                 -     PX011

3  -  Air Cooled (Condenser)           - BF042A, BU042A      =         Same                 -     PX011

3  -  Water or Glycol Cooled           -  BF046WG, BU046WG =      Same                 -     PX011

3  -  GLYCOOL Cooled                 -      BF042G, BU042G     =         Same                 -     PX011

3  -  Water or Glycol w/Econo Coil - BE036E, BU036K      =          Same                -     PX018

5  -  Air Cooled (Condensing Sec.) -  BF060E, BU060E      =          Same                -     PX018

5  -  Air Cooled (Condenser)           - BF067A, BU067A      =          Same                 -     PX018

5  -  Water or Glycol Cooled           -  BF071WG, BU071WG   =      Same                 -     PX018

5  -  GLYCOOL Cooled                 -      BF061G, BU061G     =            Same                -     PX018

5  -  Water or Glycol w/Econo Coil - BE061E, BU061K      =            Same                -     PX018

6.5 - Air, Water, Glycol Cooled           -                 None      =          None                 -     PX023

8 - Air, Water, Glycol Cooled             -                   None      =         None                 -     PX029

FH (Floor Discharge) & DH (Down Discharge) have become DS (Down discharge)

UH (Up Discharge) & VH Vertical Discharge) have become VS (Vertical or Up discharge)

FH, UH & DH, VH are synonymous except for call out on level of electronics

Tons  -  Heat Rejection   -   Old Models         -         New Models

6  -  Air Cooled              -  DH75A,  VH75A        =          None

6  -  Water Cooled        -  DH86W, VH86W       =          None

6  -  Glycol Cooled        -  DH72G, VH72G         =          None

8  -  Air Cooled              -  DH114A, VH114A        =          DS028A, VS028A

8  -  Water Cooled        -  DH127W, VH127W    =          DS028W, VS028W

8  -  Glycol Cooled        -  DH110G, VH110G       =          DS028K, VS 028K

8  -  Dual Cooling, Air    -     NONE                    =          DS028D, VS028D

8  -  Dual Cooling, H2O -     NONE                    =          DS028H, VS028H

10  -  Air Cooled              -  DH125A, VH125A     =          DS035A, VS035A

10  -  Water Cooled        -  DH138W, VH138W  =          DS035W, VS035W

10  -  Glycol Cooled        -  DH116G, VH116G      =          DS035K, VS035K

10  -  Dual Cooling, Air    -     NONE                   =          DS035D, VS035D

10  -  Dual Cooling, H2O -     NONE                   =          DS035H, VS035H

12  -  Air Cooled              -      NONE                  =          DS042A, VS042A

12  -  Water Cooled        -      NONE                  =          DS042W, VS042W

12  -  Glycol Cooled        -      NONE                  =          DS042K, VS042K

12  -  Dual Cooling, Air    -     NONE                   =          DS042D, VS042D

12  -  Dual Cooling, H2O -     NONE                   =          DS042H, VS042H

15  -  Air Cooled              -  DH199A, VH199A     =          DS053A, VS053A

15  -  Water Cooled        -  DH219W, VH219W   =          DS053W, VS053W

15  -  Glycol Cooled        -  DH192G, VH192G     =          DS053K, VS053K

15  -  Dual Cooling, Air    -     NONE                   =          DS053D, VS053D

15  -  Dual Cooling, H2O -     NONE                   =          DS053H, VS053H

20  -  Air Cooled              -  DH245A, VH245A   =          DS070A, VS070A

20  -  Water Cooled        -  DH267W, VH267W =          DS070W, VS070W

20  -  Glycol Cooled        -  DH240G, VH240G   =          DS070K, VS070K

20  -  Dual Cooling, Air    -     NONE                   =          DS070D, VS070D

20  -  Dual Cooling, H2O -     NONE                   =          DS070H, VS070H

22  -  Air Cooled              -  DH290A, VH290A   =          DS077A, VS077A

22  -  Water Cooled        -  DH315W, VH315W   =          DS077W, VS077W

22  -  Glycol Cooled        -  DH265G, VH265G   =          DS077K, VS077K

22  -  Dual Cooling, Air    -     NONE                   =          DS077D, VS077D

22  -  Dual Cooling, H2O -     NONE                   =          DS077H, VS077H

30  -  Air Cooled              -  DH380A, VH380A   =          DS105A, VS105A

30  -  Water Cooled        -  DH412W, VH412W  =          DS105W, VS105W

30  -  Glycol Cooled        -  DH363G, VH363G    =          DS105K, VS105K

30  -  Dual Cooling, Air    -     NONE                   =          DS105D, VS105D

30  -  Dual Cooling, H2O -     NONE                   =          DS105H, VS105H

Almost every reseller you will talk to has no idea how chilled water is sized. No unit is a set tonnage. 20 tons or 30 or..... It all depends on the incoming water temperature and to some extent the temperature and humidity you are looking to keep the room. If you are feeding the unit with 40 degree water or 48 degree water, or??? will give you more or less tonnage. So a CW060 /DH376 is 17.5 to 22 tons depending on the water temp and flow.

Tons  -  Heat Rejection   -   Old Models         -         New Models          -          PX & PW Models

3-5     -     Chilled Water     -  BF068C, BU068C      =                                               -     PW011

5-7.5   -    Chilled Water     -  BF102C, BU102C        =               None                       -     PW017

8-11     -  Chilled Water      -              None               =               None                       -     PW029

7.5-10   -  Chilled Water      -  FH147C, UH147C        =          CW026D, CW026U     -

10-12.5  -  Chilled Water     -  FH200C, UH200C      =          CW038D, CW038U     -

12.5-15  -  Chilled Water     -  FH248C, UH248C       =          CW041D, CW041U

15-17.5  -  Chilled Water     -  FH302C, UH302C       =          CW051D, CW051U

17.5-22  -  Chilled Water     -  FH376C, UH376C       =          CW060D, CW060U

22-27.5  -  Chilled Water     -  FH422C, UH422C     =          CW060D, CW060U

27.5-32.5 - Chilled Water    -  FH529C, UH529C      =          CW084D, CW060U

27.5-32.5 - Chilled Water    -  FH600C, UH600C      =          CW106D, CW106U

32.5-37.5 - Chilled Water    -  FH740C, UH740C      =          CW114D, CW114U
